TextHow Navigator Key Technology Evolved
First Generation (UN173)
Your first gen Navigator uses a simple transponder key with a Texas 4C chip inside the plastic head. No remote buttons on the key itself, just a chip that talks to the PATS I immobilizer when you turn the ignition. Programming is done on-board, which means it is fast, straightforward, and one of the most affordable Navigator keys we do.
Second Generation (U228)
Lincoln stepped things up here with a remote head key that combines the transponder and your lock, unlock, and trunk buttons into one unit. It runs a Texas 4D (4D63) chip on the PATS II system with a CR2032 battery powering the five remote buttons. If you have two working keys, you can actually add a third yourself using the Ford two-key method. If you are down to one key or zero, that is where we come in.
Third Generation
This is where the key type changed to a flip key with a high-security blade. The chip inside is a Texas 4D (4D63), and the immobilizer jumped to PATS IV. That means OBD-II programming is required, so no more on-board shortcuts. The blade itself is an 8-cut high-security profile that needs specialized cutting equipment, not a standard code machine.
Fourth Generation
Your fourth gen Navigator uses a smart proximity key with push-button start. The chip is an ID4D69F or PCF7953, and programming requires Ford server authentication. That means we need to connect through Ford's system to pair your new key, which adds time but we handle it all on-site. The emergency blade inside is laser-cut, and the fob runs on a CR2032 battery.
Which Key Does Your Navigator Use?
A traditional metal key with a transponder chip hidden in the plastic head. No buttons, no battery. It just needs to be cut and programmed to your Navigator's PATS I system.
Your key and remote are built into one piece. Five buttons handle lock, unlock, trunk, and panic. The transponder chip inside communicates with your PATS II immobilizer every time you start the engine.
The blade folds into the fob body. It uses a high-security 8-cut blade that requires specialized cutting equipment. Five buttons, CR2032 battery, and a Texas 4D (4D63) chip that needs OBD-II programming.
You never take this key out of your pocket. It communicates wirelessly with your Navigator for keyless entry and push-button start. A laser-cut emergency blade is hidden inside the fob for backup door access.
Navigator Key Pricing in Ventura County
Every price includes the key blank, cutting, transponder programming, and testing; no hidden fees.
EZ Car Keyz vs. the Dealer
We bring the shop to your driveway. No tow truck, no waiting room, no second trip.
Skip the Dealer - Call (805) 790-8162Common Navigator Key Problems
PATS Module Failure
No-start call on a 2003-2010 Navigator, first thing we check is the PATS module. That is the anti-theft part reading the transponder; when it fails, engine cranks but will not fire. We diagnose and reprogram your keys to a replacement module in Oxnard.
Transponder Chip Desync
Owners think the key is broken when the real problem is a transponder/computer desync. Shows up after a battery replacement or module reflash; affects 1998-2017 Navigators. Two working keys, on-board procedure can resync. Down to one, we use OBD-II.
Proximity Sensor Failure
2018+ Navigator push-button start depends on cabin sensors detecting your smart key. Sensors fail, you press and nothing. Common in coastal Ventura and Camarillo humidity. Workaround: hold the fob against the start button. Then (805) 790-8162.
High Security Blade Wear
High-security 8-cut blade on 2007-2017 Navigators wears faster than expected. Cuts round off, blade stops turning the ignition cleanly, eventually damages the cylinder, turning a $225 key job into a much bigger repair. Flip key rough? Cut fresh now.
Can You Program a Navigator Key Yourself?
You can program keyless entry remotes yourself using the ignition cycling method. For the 1998 model specifically, if you have one working programmed key, you can add a new transponder key using the PATS two-key method. No tools needed for either procedure.
Remote programming works the same way as the first gen. For transponder keys, if you have two working programmed keys, you can use the Ford PATS two-key add-a-key procedure: insert the first key, cycle the ignition 8 times, then insert the new key. If you only have one key or zero keys, self-programming will not work and you need professional EEPROM programming.
No self-programming option here. The PATS IV system with the Texas 4D (4D63) chip requires OBD-II diagnostic tools to pair a new key. The high-security blade also needs specialized cutting equipment. This one is a locksmith job.
The smart proximity key system requires Ford server authentication to program. There is no DIY path for this generation. We handle it on-site using Ford IDS equivalent tools with server access, so you do not need to tow to a dealer.
How It Works
Call or Text Us
Reach us at (805) 790-8162. Tell us your Navigator's exact year and whether you have any working keys.
We Drive to You
Wherever you are in Ventura County, from Simi Valley to Thousand Oaks to Oxnard, we come to your location.
Cut, Program, Test, Done
We cut your new key on-site using the right equipment for your generation, whether that is a standard cutter for early models or a Futura for high-security blades.
Related Services
Did You Know?
Back in 1998, Lincoln did something the luxury market had never seen before. The Navigator was the first full-size luxury SUV ever produced, built on the Ford Expedition platform with an exclusive front-end design and a leather-wrapped interior that redefined what an SUV could be. It single-handedly created the segment that Cadillac, Lexus, and Infiniti spent the next decade trying to compete in.
